Name: Cummins INSITE 8.1.1.199 Software Lite Version

Description:

Cummins INSITE 8.1.1.199 software supplies engine information quickly, getting the inside details you need. No matter what kind of equipment you run, INSITE is the one support product to have in your virtual tool box to fit every Cummins electronic engine.

Compatible with following hardware:

1. Cummins INLINE 6 Data Link Adapter
2. Cummins INLINE 5 Data Link Adapter
3. DPA5 Dearborn Protocol Adapter 5 Heavy Duty Truck Scanner
4. NEXIQ USB Link
5. XTruck USB Link
6. AUGOCOM H8 Truck Diagnostic Tool

Supported OS: Windows 7 32 bit

Supported Languages:

English, French, German, Spanish, Portuguese, Italian, Russian, Turkish, Swedish, Denish, Dutch, Finnish, Norwegian, Chinese Simplified, Japanese, Korean

Cummins INSITE 8.1.1.199 can provide your business with:

• Trip and vehicle information
• Parameter and feature adjustment
• Accurate problem diagnosis
• Complete wiring diagram sand sensor location maps
• Step-by-step trouble-shooting information
• Fault tree information
• Fault code and symptom-based diagnostics
• Engine diagnostic tests
• Tools to create templates for a group of vehicles
• Fleet management/driver reward programs(need to purchase separately)
• Audit trail information
• Enhanced ECM security(need to purchase separately)

Functions:

Support SAE J1708/J1587 and J1939/CAN data links
Support USB full speed port at up to 2M baud rate
Support RS-232 PC/PDA serial port at up to 115.2k baud rate
It's fully compliant with TMC's RP1210 standard
Small enough to fit in pocket
Aluminum housing provides ruggedness
Derives 8 V to 50 V DC power from vehicle
Includes advanced processor for maximum speed and performance
Internal Flash memory allows firmware upgradeability
Includes 5 LEDs to indicate power and USB, RS-232, J1708/J1587, and J1939/CAN communications
Rated for -40 to +85 degree centigrade operating temperature

Notice:

1. You can add authorization for Fleet Management/Driver Reward Programs and Enhanced ECM Security at USD160 for each.

2. Cummins INSITE 8.1.1.199 is offered in 4 functional levels: Basic, Lite, RSGR and Pro, ranging from a read only access level to full-function access and capability for the service professional.

This is Cummins INSITE 8.1.1.199 software is Lite Version supports 500 times. Software needs activation, one activation includes 500 times.
