Name: Yanhua Mini ACDP-2 Programming Master Basic Module
Description:
Yanhua Mini ACDP 2 Programming Master Basic Module.
Supports USB and Wireless Connection. Works on PC/Android/iOS
ACDP-1 VS ACDP-2:
ACDP-1: Wireless connection only
ACDP-2: Wireless and USB connection, connect ACDP host with Android, iOS and PC devices via USB without Bluetooth adapter.
Notice:
ACDP Module 3, 8, 12, 15, 18, 19, 25 can not be used with ACDP-2.
Features:
No need to remove chip.
No need to soldering.
No need to cut the line.
No need to lift the pin.
Intelligent pin detection
Data reading and writing is safe and reliable
Connection Upgrade:
1. USB direct connection, plug and play
2. WiFi connection, more freedom.
Data Transfer Upgrade:
Data preservation and transmission, faster, more stable, more secure.
How to bind Yanhua Mini ACDP-2:
1. Bind directly through the USB cable. The 3 USB cables correspond to Android, iOS, PC respectively. After binding the device in this way, the USB cable must be connected to the host and the mobile phone, and it cannot be used without the USB cable. Disconnect the USB cable and the device will lose connection.
2. Configure WiFi or hotspot binding through the USB cable. The binding process of this method requires a USB connection, and then enter the WiFi or hotspot name and password to complete the binding. After binding, you can unplug the USB cable and use it wirelessly.
3. Configure WiFi or hotspot binding through the Bluetooth of the mobile phone. This method is the same as the binding method of the 1st generation host. Wireless use after binding.
 |
